PETG (Polyethylene Terephthalate Glycol)
polymeramorphous/semi-crystalline copolyester thermoplastic
Polyethylene terephthalate glycolPET-GPETG+eSUN PETGPrusament PETGColorFabb PETGGlycol-modified PET
Mechanical & thermal properties — 2 conditions
| Property | FDM as-built (XY) | FDM as-built (Z — upright) |
|---|---|---|
| Elastic modulus | 2–3 GPa | — |
| Ultimate tensile strength | 44–56 MPa | 25–38 MPa |
| Elongation at break | 20.0–50.0 % | 5.0–18.0 % |
| Density | 1.25–1.29 g/cm³ | — |
| Glass transition (Tg) | 75–85 °C | — |
| As-built surface Ra | 7.0–18.0 µm | — |
Values shown as min–max where a spread is reported, otherwise as typical ± unit. Ranges reflect inter-source variation, not single-sample scatter. All values are for AM-processed specimens unless noted.
Engineering considerations
- Material selection vs PLA: choose PETG over PLA when any of these apply: (1) temperatures above 50°C, (2) impact or dynamic loading, (3) snap-fits or clips, (4) chemical exposure, (5) food/water contact. Use PLA when stiffness is paramount and temperature is controlled.
- Material selection vs ABS: choose PETG over ABS when: (1) no heated chamber available, (2) food contact required, (3) odour is a concern, (4) chemical resistance needed. Use ABS when: (1) acetone smoothing is needed, (2) maximum heat resistance within FDM polymers is required, (3) painting/plating finishes are planned.
- Moisture management: dry PETG filament at 65–70°C for 4–8h before printing if stored without desiccant for more than a few days. Wet PETG shows stringing, blobbing, and reduced mechanical properties. Vacuum-seal with silica gel for long-term storage.
- Print settings sensitivity: PETG is highly print-settings-sensitive. UTS can vary ±20% with nozzle temperature and speed changes. Run characterisation samples before structural applications. Higher nozzle temperature (245–250°C) generally improves layer adhesion and Z-direction strength.
- Wall design: PETG's ductility means thick walls increase toughness disproportionately. For impact-prone enclosures, prefer 2–3 wall perimeters over high infill. The outer walls carry most impact load.
- Chemical resistance caveat: while PETG resists dilute acids and bases well, it is attacked by concentrated acids and esters. Verify chemical compatibility with specific reagents for laboratory or industrial applications before deployment.
- Transparency: for optical parts, use transparent PETG with 0% infill (single-wall vase mode) or near-100% infill and minimal layers. Annealing can increase haze. XY-oriented specimens have better clarity than Z-oriented due to layer line visibility.
Advantages
- Significantly better impact resistance than PLA: ductile failure mode (20–50% elongation vs. PLA 3–6%) means PETG bends rather than shatters
- Higher temperature resistance than PLA: HDT ~72°C vs ~55°C — survives hot cars and warm environments
- Better chemical resistance than PLA and ABS: resistant to dilute acids, bases, and many alcohols. Not attacked by water-based solutions
- Food-safe in appropriate grades: PETG is the same polymer family as PET used in food bottles — food-contact certified grades widely available
- Good optical clarity: PETG can be printed in transparent grades with good light transmission — useful for light diffusers and display parts
- Semi-flexible without being rubbery: slight flex on impact prevents catastrophic failure while maintaining dimensional stability
- Easier to print than ABS: no heated chamber required, minimal warping, good bed adhesion, lower odour
- Recyclable: PETG (like PET) can be recycled via standard plastics recycling streams
Limitations
- No solvent smoothing: unlike ABS, PETG cannot be smoothed with acetone. Surface finishing requires sanding, priming, or chemical treatments (specific to grade). Finish quality is harder to achieve than with ABS
- Lower stiffness than PLA (2.2 vs 3.5 GPa): PETG parts flex slightly under load — not ideal for high-rigidity applications
- Moisture sensitivity: PETG is hygroscopic. Wet filament causes stringing, bubbles, and poor surface quality. Dry at 65–70°C for 4–8h if stored unsealed
- Stringing tendency: PETG has higher tendency to string between features compared to PLA — requires careful retraction settings
- Not suitable for prolonged UV exposure without UV-stabilised grades: standard PETG yellows over time outdoors
- Over-adhesion to print beds: PETG sticks extremely well to glass and smooth surfaces — use PEI, glue stick, or release agent to allow part removal without damage
- Density penalty: heavier than ABS (1.27 vs 1.05 g/cm³) for equivalent geometry — matters in weight-critical applications
Typical applications
Mechanical parts requiring toughness and some heat resistance: brackets, mounts, enclosuresWater bottles, food contact containers, and fluid handling components (food-safe grades)Medical device housings and instrument casings requiring chemical resistanceElectronic enclosures where occasional heat exposure is possibleSnap-fit and clip mechanisms where ductility prevents brittle fractureTransparent or translucent parts — PETG has excellent optical clarityAquarium equipment and wet-environment applications (better hydrolysis resistance than PLA)Consumer product casings and display componentsProtective covers and guards for machinery
Industries
consumerindustrialmedicalelectronics
Standards & certifications
iso-527-3-2018established
Tensile testing of plastic specimens from FDM PETG parts
consumerindustrial
ISO 527-2 Type 1B more commonly used for FDM test coupons. PETG food-contact grades may meet EU Regulation (EC) No 10/2011 for plastic materials in contact with food.
