H13 Tool Steel
metalchromium-molybdenum hot-work tool steel
AISI H131.2344 (DIN)X40CrMoV5-1 (EN)SKD61 (JIS)HS6-5-2 (partial equiv.)Tool Steel H13EOS Tool Steel H13
Composition — AISI H13 / DIN 1.2344 / EN X40CrMoV5-1
| Element | Min % | Max % | Notes |
|---|---|---|---|
| Fe | bal. | balance | |
| C | 0.32 | 0.450 | Carbon controls martensite hardness; higher C → harder martensite but reduced toughness. LPBF powder typically at lower end (~0.35%) for improved weldability. |
| Cr | 4.75 | 5.500 | Primary hardenability element; forms M₂₃C₆ and M₇C₃ carbides during secondary hardening (tempering) |
| Mo | 1.10 | 1.750 | Mo₂C formation during tempering (secondary hardening peak); significantly improves high-temperature strength and temper resistance |
| V | 0.80 | 1.200 | VC precipitates resist grain coarsening at austenitising temperature; primary driver of secondary hardening at 550–600°C temper |
| Si | 0.80 | 1.200 | Solid solution strengthener; improves oxidation resistance at elevated temperatures |
| Mn | 0.20 | 0.500 | |
| P | — | 0.030 | |
| S | — | 0.030 | Low S critical for toughness; minimises MnS inclusion formation |
| Ni | — | 0.300 |
Mechanical & thermal properties — 3 conditions
| Property | LPBF + Stress-relieved (550°C/2h, XY) | LPBF + Q+T Double Temper (44–48 HRC, XY) | LPBF + Q+T Double Temper (Z — build direction) |
|---|---|---|---|
| Elastic modulus | 210 GPa | 210 GPa | — |
| Yield strength (0.2%) | 1250–1450 MPa | 1200–1400 MPa | 1160–1360 MPa |
| Ultimate tensile strength | 1500–1700 MPa | 1380–1620 MPa | 1340–1580 MPa |
| Elongation at break | 2.0–6.0 % | 7.0–12.0 % | 6.0–10.0 % |
| Hardness (HV) | 520–620 HV10 | 440–510 HV10 | — |
| Density | 7.80 g/cm³ | 7.80 g/cm³ | — |
| Thermal conductivity | 22.0–27.0 W/m·K | — | — |
| CTE | 10.8–12.5 µm/m·K | — | — |
Values shown as min–max where a spread is reported, otherwise as typical ± unit. Ranges reflect inter-source variation, not single-sample scatter. All values are for AM-processed specimens unless noted.
Engineering considerations
- Conformal cooling design rules: minimum channel diameter 3 mm (surface roughness and thermal resistance); minimum channel-to-cavity wall distance 1.5× channel diameter; pitch 2.5–3× diameter for uniform cooling. Water flow velocity >0.5 m/s for turbulent flow (Re > 2300) — critical for heat transfer.
- Preheating protocol: 200°C minimum base plate preheat in the LPBF machine. EOS M 290/M 300 achieve this via base plate heater. Without preheat, delamination and through-cracks are almost certain at H13 carbon content.
- Post-LPBF sequence: LPBF (200°C preheat) → stress relief (550°C/2h, furnace cool) → rough machine → austenitise (1020°C/30–45 min vacuum) → polymer/oil quench → double temper (560°C/2h + 560°C/2h) → finish machine → surface treat (nitriding optional).
- Retained austenite: single-temper H13 retains 5–10% austenite which transforms to martensite during moulding service cycles, causing dimensional instability. Always double-temper.
- Surface treatment: LPBF H13 can be nitrided (plasma or gas) to achieve surface hardness of 900–1000 HV to ~0.1–0.2 mm depth. Improves abrasion resistance for glass-filled or mineral-filled polymer moulding. Nitriding temperature (480–530°C) must be below temper temperature to avoid softening.
- DED repair: for feature addition or worn cavity repair, use DED with ER431 or H13 powder wire. Post-DED temper at 560°C for 2h. Verify hardness and chemical composition in repair zone before return to service.
- Cooling channel inspection: internal channel quality from LPBF can be verified by flushing with pressure drop testing or borescope inspection. Surface Ra of ~12–20 µm in as-built channels is acceptable — turbulent flow insensitive to this roughness range.
- Dimensional stability: H13 expands ~0.06–0.08% on austenitising and contracts ~0.04–0.05% on tempering (net change ~+0.02–0.03%). Account for heat treatment dimensional change in LPBF near-net geometry or machine post-HT.
Advantages
- Primary AM use case: conformal cooling channels reduce injection mould cycle time 20–40% vs straight-drilled cooling
- Full Q+T cycle achieves conventional H13 properties — wrought-equivalent hardness (44–48 HRC) and toughness
- Good thermal fatigue resistance: Mo and V carbides resist thermal softening at mould service temperatures (150–350°C)
- Low anisotropy after Q+T — austenitising recrystallises LPBF columnar texture
- DED enables repair of worn conventional H13 tooling (cost 20–30% of replacement die)
- Rapid prototyping of complex die geometry without EDM lead time
Limitations
- Mandatory 200–250°C base plate preheating during LPBF — without preheat, through-layer hot cracks form due to high thermal gradient and hard martensite brittleness
- As-built and stress-relieved conditions are not serviceable — full Q+T cycle required for final tooling application
- High risk of hydrogen-induced delayed cracking if not properly stress-relieved before quench
- Austenitising temperature (1020°C) causes solution of fine LPBF carbides — some AM microstructural advantage is lost during HT
- Slower printing than austenitic stainless or aluminium — high carbon and chromium content create fine process window
- EDM after LPBF requires re-tempering: EDM creates a white layer (untempered martensite) which must be removed or re-tempered to prevent brittle fracture
- Not suitable for non-tooling structural applications — excessive hardness with low ductility in stress-relieved state
Typical applications
Injection moulding inserts with conformal cooling channelsDie casting tooling — H13 is the primary hot-work die steel globallyExtrusion dies and tooling for aluminium profilesForging dies and progressive stamping toolingHot-work tooling for glass and plastics processingAerospace forming tooling (superplastic forming, hydroforming)Repair and feature addition on worn conventional H13 tooling (DED process)Rapid tooling inserts for prototype injection moulding
Industries
toolingautomotiveindustrialaerospacedefence
