GRCop-84
metalcopper alloy — dispersion/precipitation strengthened
Cu-8Cr-4NbGRCop84NASA GRCop-84Glenn Research Copper-84
Composition — NASA GRC internal specification — Cu-8Cr-4Nb (at%)
| Element | Min % | Max % | Notes |
|---|---|---|---|
| Cu | — | — | balance — pure copper matrix provides thermal conductivity |
| Cr | — | — | 8 at% (~5.0 wt%); forms Cr₂Nb Laves phase for high-temperature strength |
| Nb | — | — | 4 at% (~5.8 wt%); key Laves-phase former; Cr₂Nb pins dislocations at 700°C |
| O | — | 0.050 | Oxygen contamination degrades thermal conductivity and promotes porosity; strict atmosphere control required |
Mechanical & thermal properties — 2 conditions
| Property | LPBF as-built (XY) | LPBF aged 500°C/4h (XY) |
|---|---|---|
| Yield strength (0.2%) | 230–320 MPa | 300–380 MPa |
| Ultimate tensile strength | 260–350 MPa | 340–420 MPa |
| Elongation at break | 15.0–35.0 % | 12.0–28.0 % |
| Density | 8.83 g/cm³ | — |
| Thermal conductivity | 305.0–340.0 W/m·K | 300.0–330.0 W/m·K |
| Max service temperature | 700 °C | — |
Values shown as min–max where a spread is reported, otherwise as typical ± unit. Ranges reflect inter-source variation, not single-sample scatter. All values are for AM-processed specimens unless noted.
Engineering considerations
- Green laser selection: If budget allows, specify a green-laser LPBF system (e.g., Trumpf TruPrint with green module, or Aconity dedicated green system). Copper absorptivity at 532 nm is ~40% vs ~5% at 1064 nm — dramatically more stable melt pool and lower porosity.
- High-power IR approach: If green laser is unavailable, use IR power ≥400 W with scan speeds <500 mm/s to achieve sufficient energy deposition. Expect higher spatter and porosity; require systematic parameter development and CT verification.
- Atmosphere control: Use high-purity argon (<10 ppm O₂, <10 ppm H₂O). Even minor oxidation forms Cu₂O inclusions that reduce thermal conductivity and weaken grain boundaries. Do not reuse powder without oxygen content verification.
- Post-processing: Aging at 500°C/4h in vacuum or argon furnace before service. Do not anneal — full anneal removes precipitates and reduces elevated-temperature strength.
- Thermal management design: Wall thickness in cooled chambers limited by channel geometry and pressure requirements, not thermal resistance. GRCop-84's high conductivity allows thinner walls; verify structural integrity with LPBF-specific material data, not handbook wrought copper data.
- Inspection: Use helium leak testing for pressure channels (critical for combustion chambers). CT scanning to detect subsurface porosity clusters before pressure testing.
- Powder storage: Copper powder is less pyrophoric than Ti or Al powders but must still be stored in sealed, dry containers. Moisture absorption increases O content in the melt.
Advantages
- Unique combination of high thermal conductivity (~323 W/m·K) and elevated-temperature strength — no other AM metal offers both
- Retains ~70% UTS at 700°C; standard copper alloys lose strength above 200°C
- Cr₂Nb Laves phase is thermally stable — does not over-age or dissolve below 900°C
- LPBF enables complex internal channel geometries (conformal cooling) impossible in conventional manufacturing
- Near-pure-copper thermal conductivity allows thinner wall sections than CuCrZr for equivalent cooling
- NASA-proven material heritage in multiple rocket engine programmes (SLS RS-25, Vulcan BE-4 development)
Limitations
- Requires green laser (515–532 nm) for consistent LPBF processing; green laser LPBF systems are significantly more expensive than standard IR systems
- High-power IR fibre lasers can process GRCop-84 but require very specific parameters and show higher porosity and spatter vs green laser
- Powder is 10–20× more expensive than 316L stainless; cost-justify strictly on application requirements
- Oxidation risk during build — strict atmosphere control (<50 ppm O₂) mandatory; surface oxidation degrades thermal conductivity
- No widely adopted AM-specific material standard; qualification must follow OEM/NASA-internal specifications
- Limited supplier base for GRCop-84 powder; Elementum 3D is the primary commercial supplier
- Post-processing (machining) requires appropriate tooling due to copper's gummy cutting behaviour
Typical applications
Regeneratively-cooled rocket combustion chamber liners (inner wall)Rocket engine nozzle throats and nozzle extensionsThrust chamber injector faceplatesCryogenic rocket engine turbopump hot-section componentsHigh-heat-flux heat exchangers in propulsion test standsPlasma-facing components for fusion research (experimental)
Industries
aerospacedefenceenergy
