Waspaloy®
metalnickel superalloy — γ'-precipitation-hardened
UNS N07001Alloy 685AMS 5544AMS 5704PWA 683Ni-Cr-Co superalloy
Composition — UNS N07001 / ASTM B637 / AMS 5544
| Element | Min % | Max % | Notes |
|---|---|---|---|
| Ni | bal. | balance | |
| Cr | 18.00 | 21.000 | Oxidation resistance and solid-solution strengthening; forms Cr₂O₃ scale |
| Co | 12.00 | 15.000 | Solid-solution strengthening; raises γ' solvus temperature for better high-T stability |
| Mo | 3.50 | 5.000 | Solid-solution strengthening; corrosion resistance in reducing environments |
| Al | 1.20 | 1.600 | γ' (Ni₃Al,Ti) former — primary precipitate strengthener |
| Ti | 2.75 | 3.250 | γ' former (combined Al+Ti drives γ' fraction); must be controlled for hot-cracking risk in LPBF |
| Zr | 0.02 | 0.120 | Grain boundary strengthening; carbide former |
| B | 0.00 | 0.010 | Grain boundary strengthening; key for creep resistance. Also contributes to hot-cracking risk in LPBF at high B content |
| C | 0.02 | 0.100 | M₂₃C₆ and MC carbides at grain boundaries — beneficial for creep but must not be excessive |
| Fe | — | 2.000 | |
| Mn | — | 0.100 | |
| Si | — | 0.150 | |
| Cu | — | 0.100 | |
| S | — | 0.015 | |
| P | — | 0.030 |
Mechanical & thermal properties — 3 conditions
| Property | LPBF stress-relieved (1050°C / 1h / AC) (XY) | LPBF SA + double-age (XY) — primary service condition | LPBF SA + double-age (Z) |
|---|---|---|---|
| Elastic modulus | — | 197–217 GPa | — |
| Yield strength (0.2%) | 700–870 MPa | 793–1000 MPa | 780–950 MPa |
| Ultimate tensile strength | 960–1150 MPa | 1207–1380 MPa | 1160–1320 MPa |
| Elongation at break | 12.0–28.0 % | 12.0–28.0 % | 10.0–26.0 % |
| Hardness (HV) | — | 365–430 HV10 | — |
| Fatigue strength | — | 500–690 MPa | — |
| Density | 8.19 g/cm³ | — | — |
| Thermal conductivity | 11.7 W/m·K | — | — |
| CTE | 12.8–14.2 µm/m·K | — | — |
| Max service temperature | — | 870 °C | — |
Values shown as min–max where a spread is reported, otherwise as typical ± unit. Ranges reflect inter-source variation, not single-sample scatter. All values are for AM-processed specimens unless noted.
Engineering considerations
- Hot-cracking mitigation strategy: (1) elevated preheat 200–400°C reduces thermal gradient; (2) island scan strategy reduces thermal accumulation; (3) low VED reduces heat input per unit volume; (4) support strategy that limits constraint at high-stress locations. Even with mitigations, 100% FPI + CT inspection of every Waspaloy part is strongly recommended before heat treatment.
- Heat treatment control: solution anneal at 1080°C ±10°C for exactly 4h is critical. Under-annealing (< 4h or < 1070°C) leaves primary γ' undissolved, reducing subsequent ageing response. Over-annealing (> 1100°C or > 6h) causes grain coarsening. Use vacuum or Ar atmosphere.
- Cracking detection: fluorescent penetrant inspection (FPI per ASTM E1417) after machining. Industrial CT scanning (0.1 mm resolution or better) is preferred for complex internal features. Do not accept parts with cracks > 0.5 mm before heat treatment.
- Comparison with IN718: choose Waspaloy when service temperature > 650°C and creep/fatigue governs design. Below 650°C, IN718 provides equivalent or better properties with lower processing risk and cost. If design allows downgrading from 850°C to 700°C service, IN718 may be substituted at significant cost and risk reduction.
- Alloy stability: γ' coarsening rate increases sharply above 870°C. If temperature excursions above 870°C are possible in service, use a more stable alloy (René 88DT, IN939, CMSX-4) or account for γ' coarsening in life prediction.
- Surface treatment: as-built LPBF surfaces have Ra 10–20 µm — unacceptable for rotating disc faying surfaces (require Ra < 1.6 µm per most aerospace standards). Plan for full machining of all functional surfaces. Electropolishing or grit blasting for non-machined surfaces before coating.
- Powder reuse: Waspaloy powder is susceptible to Al/Ti oxidation during LPBF processing. Characterise each reuse lot for chemistry (ICP-OES) and morphology (ASTM F3049). Limit reuse to 10 cycles or less; recalibrate oxygen content after each cycle.
Advantages
- Outstanding combination of creep strength and fatigue resistance at 700–870°C — surpasses IN718 above 650°C
- γ' precipitation strengthening provides superior strength retention at high temperature vs. solid-solution alloys
- Good oxidation resistance to ~1000°C in air and combustion gases
- LPBF enables complex internal cooling passages for compressor disc cooling — not achievable in forging
- Established wrought property database (AMS 5544) provides design baseline for LPBF qualification
- No Laves phase issues (unlike IN718) — no Nb-rich eutectic segregation during solidification
Limitations
- High hot-cracking susceptibility in LPBF — high (Al+Ti) content drives γ' precipitation during layer reheating, causing strain-age cracking (SAC)
- Requires elevated preheat (200–400°C) and tightly controlled scan strategy — significantly higher LPBF complexity than IN718
- Limited LPBF parameter databases — fewer published studies vs. IN718 or IN625; higher parameter development investment needed
- Mandatory full heat treatment (SA + double-age) — complex 3-step process with tight temperature control (±10°C)
- Residual microcracking is difficult to detect without CT or FPI — quality assurance cost is high
- Very high powder cost (premium Ni superalloy with Co) — 2–3× more expensive than IN718 powder
- Restricted to LPBF — DED is theoretically possible but cracking risk is higher due to lower cooling rates
- Hot-cracking risk is exacerbated by high build temperatures — careful thermal management during build is essential
Typical applications
Gas turbine compressor discs and impellers — primary application exploiting high fatigue strength at 700–870°CTurbine disc bores and bolt holes — where fatigue crack initiation is criticalCompressor rotor blades — stationary and rotatingHigh-temperature fasteners and bolts for gas turbine assembliesCombustion casing components operating at intermediate temperaturesIndustrial gas turbine hot section componentsRocket engine turbopump components operating at cryogenic-to-hot cycle conditions
Industries
aerospaceenergydefence
Standards & certifications
ASTM-F3049established
Powder feedstock characterisation for LPBF Waspaloy
aerospaceenergy
No dedicated AM Waspaloy standard. Aerospace qualification follows OEM-specific plans. AMS 5544 (wrought) used as property benchmark.
NADCAP-AC7110-14established
NADCAP accreditation for metallic AM parts — required for aerospace flight-critical Waspaloy parts
aerospace
